Brand Name : TORICH
Model Number : 08X18H10T
Certification : ISO,SGS,Other,ROHS
Place of Origin : Zhejiang/China
MOQ : 1Ton
Price : 800-1300 USD/Ton
Payment Terms : L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability : 60000 Ton/Tons per Year
Delivery Time : 20-30days upon products
Packaging Details : In bundles or in wooden boxes.
Alloy Or Not : Stainless
Corrosion Resistance : High
Mode Of Production : seamless tube
Surface : Annealed & pickled
Strength : High
Out Diameter : 6-630mm
Size : 1/4 inch
Type : Tube
Package : bunding
Product : 321 Stainless Steel Tube
Flexibility : Low
Chemical Composition : Stainless steel
Steel grade : 300 Series,200 Series,400 series,TP316,200/300 series
Application : Corrosion-Resistant
Welding line type : ERW,Seamless,Spiral Welded,TIG
Standard : GB,ASTM,DIN,AISI,JIS
Thickness : 1-100mm
Length : 1m-12m,6m or as customers' request,30mm or custom,0-12m,2.5-8m
Product name : stainless steel pipe/tube,AISI 304 stainless steel pipe,pipes,Stainless Steel Tubing,Fast Sell square stainless steel pipe price per ton
Material : 200 Series/300 Series/400series,200,202,AISI 201,400 series
Shape : square,Round.square.Rectangle,Slot,wire drawing,rectangular
Finish : Brush Polish,hairline,BA,mirror ETC,pickled
Technique : Cold Rolled Hot Rolled,Cold Drawing
Grade : 201/202/304 /304L/316/316L321/310s/410/420/430/440/439ect,201,316L,202,304L 316 316L 310s 321 321H 347 347H
Name : Seamless Stainless Steel Tubing,stainless steel telescopic tube,Stainless Steel Circular Corrugated Water Pipe
The thin wall stainless steel tubes under GOST 10498 standard comprise primarily of three stainless steel grades: 06X18H10T, 09X18H10T, and 08X18H10T. These materials are austenitic stainless steels known for their excellent corrosion resistance, good mechanical properties, and weldability. They are widely used in the manufacture of thin-walled tubes that require high resistance to oxidizing and reducing media, commonly employed in chemical, food, and pharmaceutical industries.
Element | 06X18H10T (%) | 09X18H10T (%) | 08X18H10T (%) |
---|---|---|---|
Carbon (C) | 0.06 max | 0.09 max | 0.08 max |
Silicon (Si) | 0.8 max | 0.8 max | 0.8 max |
Manganese (Mn) | 2.0 max | 2.0 max | 2.0 max |
Phosphorus (P) | 0.035 max | 0.035 max | 0.035 max |
Sulfur (S) | 0.03 max | 0.03 max | 0.03 max |
Chromium (Cr) | 17.5 - 19.5 | 17.0 - 19.0 | 17.0 - 19.0 |
Nickel (Ni) | 9.0 - 11.0 | 8.0 - 10.5 | 8.0 - 10.5 |
Titanium (Ti) | 0.5 - 0.7 | - | - |
Nitrogen (N) | - | - | - |
Note: The 06X18H10T contains Titanium for stabilization, enhancing resistance against intergranular corrosion.
Property | 06X18H10T | 09X18H10T | 08X18H10T |
---|---|---|---|
Tensile Strength (MPa) | 520 - 700 | 520 - 700 | 520 - 700 |
Yield Strength (MPa) | ≥ 205 | ≥ 205 | ≥ 205 |
Elongation (%) | ≥ 40 | ≥ 40 | ≥ 40 |
Hardness (HB) | ≤ 200 | ≤ 200 | ≤ 200 |
Impact Toughness (KV) | ≥ 35 J at 20°C | ≥ 35 J at 20°C | ≥ 35 J at 20°C |
GOST Grade | AISI/ASTM Equivalent | EN Standard Equivalent |
---|---|---|
06X18H10T | AISI 321 | EN 1.4541 |
09X18H10T | AISI 304 | EN 1.4301 |
08X18H10T | AISI 304L (similar) | EN 1.4306 (close grade) |
A: manufacturer,also can do trading.
A: Generally speaking,it is 10-15 days if the goods are in stock,or it is 30-40 days if the goods are not in stock, it is according to quantity.
A: Yes, we could offer the sample for free charge but need pay the cost of freight.
A: Payment<=2000USD, 100% in advance. Payment>=2000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact with me.
![]() |
